• Race Replica ProGraphix® Painted Body
  • 1/16 Scale pre-painted body with applied decals
  • Scale dimensions and looks of actual short course race trucks
  • Scale front and rear tube-style bumpers
• Waterproof XL-2.5™ Electronic Speed Control
  • Innovative waterproof design
  • Three drive profiles
    • Sport Mode - forward / brake / reverse
    • Race Mode - forward / brake
    • Training Mode™ - 50% forward / brake / 50% reverse (patented)
  • Traxxas EZ-Set® one-button setup
  • High-capacity heat sink
  • LiPo and NiMH compatible with two-stage low-voltage detection
• Titan 550 Motor
  • Powerful Titan™ 12T 550 modified motor with internal cooling fan
  • Oversized armature for big torque and increased power handling
  • Virtually maintenance-free operation
• TQ™ 2.4GHz 2-Channel Radio System
  • Ergonomic transmitter with internal antenna
  • Traxxas #6519 3-channel micro receiver with fail-safe security
  • Patented O-ring sealed watertight receiver box keeps the micro receiver dry
• Includes Battery and Charger
  • 2-amp 12V DC Peak Detecting Fast Charger
  • 1200mAh Traxxas 6-cell 7.2V NiMH battery with iD™
• Fiber-Composite Monocoque Chassis
  • Low-CG design for improved handling
  • Tough skid plates for driveline protection
  • All electronics securely fastened to chassis
• Dual Integrated Battery Compartments
  • Quick-release battery doors for fast pack changes
  • Intake and exhaust cooling vents keep battery temperatures down
  • Accepts 1/16 scale NiMH and LiPo batteries
• Transmission and Driveline
  • Full-time shaft-driven 4WD
  • Sealed heavy-duty transmission
  • Adjustable slipper clutch
  • Sealed, silicone-filled differentials with steel gears
  • Heavy-duty telescoping U-joint driveshafts
• Steering
  • Digital waterproof Traxxas #2080 steering servo
  • Servo horn with integrated servo saver
• Suspension
  • Twin-arm pivot ball suspension
  • Progressive rocker-arm damping for extreme travel
  • Captured rod ends won't pop off
• Springs and Shocks
  • Inboard fully adjustable oil-filled GTR™ shocks
  • Adjustable pre-load collars
  • Red powder-coated springs
• Wheels and Tires
  • Pre-glued all-terrain tires with high-performance foam inserts
  • Satin chrome 5-spoke beadlock style wheels
• Rubber-Sealed Ball Bearings
• Precision Hex Hardware
• Backed by Unparalleled Traxxas Support and Parts Availability

Model Specs

Model Name:1/16 Slash 4X4

Model Type:Short Course Trucks

Model Skill Level:1

Scale:1/16

Weight:2.2 pounds (1 kg)

Length:14 inches (356 mm)

Width:7.3 inches (185 mm)

Front Track:7.3 inches (185 mm)

Rear Track:7.3 inches (185 mm)

Height:4.92 inches (125 mm)

Wheelbase:8.1 inches (206 mm)

Drivetrain:Shaft-driven 4WD

Transmission:Heavy-duty with steel idler gear

Differential Type:Hardened steel bevel, sealed

Gear Ratio (Internal):5.04:1

Gear Pitch:48 pitch

Servo(s):2080 digital waterproof

Radio System:TQ™ 2.4 GHz 2-channel radio

Motor Specs

Motor Name:Titan® 12T 550

Motor Type:High-speed brushed motor

Motor Weight:8.47 ounces (240 g)

Motor Length:3.07 inches (78 mm) overall length, 2.25 inches (57 mm) can length

Motor Diameter:1.41 inches (36 mm)

Motor Shaft Size:3 mm

Motor Connector Type:Bullet

ESC Specs

ESC Name:Waterproof XL-2.5 ESC with low-voltage detection

ESC Type:Brushed

ESC Case Size:46.5 mm / 26.5 mm / 22 mm

ESC Weight:1.16 ounces (33 g)

Motor Connectors:Bullet

Battery Connectors:Traxxas High Current Connector

ESC Power Wire:16 gauge
