• VXL-8s™ Waterproof Electronic Speed Control

  • New aggressive tune for more power at any RPM
  • 8s LiPo compatible
  • Integrated cooling fan
  • Real-time telemetry via Traxxas Link
  • 3-LED status indicators
  • Machined heat sink
  • Powered accessory ports
  • 10-gauge silicone wire
  • Integrated protection circuits
• Velineon®1200XL Brushless Motor
  • 4-pole 1275 kV
  • 5 mm output shaft
  • Oversize aluminum heatsink for improved cooling
  • Dual cooling fans
• Up to 60+ mph with Two 4s LiPo Batteries (sold separately)
• Traxxas Stability Management®
  • Improves straight line acceleration and braking on low-traction surfaces
  • Never dulls throttle or slows the truck
  • Adjusts from off to 100% assistance from the transmitter
• TQi™ 2.4 GHz High Output Radio System
  • TQi 2-channel transmitter
  • Traxxas Link enabled
  • 2.4 GHz 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
  • Automatically stores and loads settings for up to 30 Traxxas Link™-enabled models
  • Programmable Multi-Function knob
  • Adjustable steering and throttle percentage (dual rates)
  • Adjustable steering and throttle sensitivity (exponential)
• X-Truck™ Drivetrain
  • Full-time shaft-driven 4-wheel drive
  • Heavy-duty steel CV driveshafts & axles
  • Splined aluminum center driveshaft
  • Machined aluminum stub axles
• Transmission
  • Mod-1 pinion and spur gears
  • Fixed gear mesh system
  • Torque-Biasing Center Drive
• X-Truck Differentials
  • Heavy-duty sealed 4-gear design
  • Large scale steel ring and pinion gears
  • Splined outdrives attached with external thru-bolt method
  • New bulkhead and covers increase bearing support
• Rock-Solid Motor Mounting System
  • Precise preset gear mesh adjustments
  • 4 keyed pins lock the motor in place
  • Motor retention separate from gear mesh
• GTX™ Shocks

  • Machined aluminum threaded body
  • Extra-large bore and capacity
  • 5.2 mm damper shaft
  • Lower seal cartridge includes integrated wiper seal combination
  • Height-adjustable spring retainer
  • Heavy-duty composite shock caps with pivot balls
  • Lower spring perches bolted on
• WideMaxx® Suspension

  • Performance-optimized geometry
  • Extra-wide suspension arms

    • Made from our strongest cold-weather material
  • Double-shear connections
  • High-strength steel suspension pins with retainers
  • 4 mm machined pivot balls
  • Fixed high-strength camber and toe links
  • Heavy-duty steering blocks and axle carriers
  • Oversized wheel bearings
• Steering
  • Powerful 365 oz-in steering servo
  • Heavy-duty cam-style servo saver
  • Dirt evacuation channels
  • Fully waterproof
• Ultra-Low-CG Chassis Design
  • Modular chassis with interlocking bulkheads

    • Low center of gravity for improved handling
    • Flat bottom design
    • Heavy-duty interlocking skid plates
    • High-strength buttressing on shock towers
  • Dual snap-lock battery compartments

    • Protects batteries from side impacts
    • Allows secondary battery-clip security
  • Interlocking components for tight tolerances
  • Wire management for clean appearance
• Patent-Pending Clipless Body
  • Snaps in place in just seconds
  • Secure body latches are easy to use
  • Clipless body mounting system
  • Rigid internal frame
  • Dual high-capacity cooling ducts
  • Molded body reinforcements for tear-through protection
  • Protective top skids
  • Rugged high-downforce rear wing
• Heavy-duty Bumpers
  • Reinforced front bumper and rear wing support
    • Absorb impact forces while retaining shape
  • Heavy-duty front bumper and support
  • Reinforced rear wing support
  • Nerf bars for side impact resistance
  • Heavy-duty wheelie bar with carry handle
• Wheels and Tires
  • 7.4″ Gravix™ race tires
    • Low sidewall for sharp turn-in response
    • Thick center carcass resists ballooning at high speed
    • Lower rotational mass for faster acceleration
  • 3.8″ matte black XRT® wheels
  • High-strength glue and bead design
  • Huge 24 mm splined wheel hubs
• Sealed Ball Bearings
• Hex hardware with Rust-Resistant Black Oxide Coating

Model Specs

Model Name:XRTModel

Type:Monster

TruckModel Speed:60+ mph with dual 4s LiPo batteries and optional gearing

Model Skill Level:5Scale:X-Truck™

Weight:21.03 pounds (9.54 kg)

Length:31.41 inches (798 mm)

Width:23.43 inches (595 mm)

Front Track:23.43 inches (595 mm)

Rear Track:23.43 inches (595 mm)

Height:10.15 inches (258 mm)

Center Ground Clearance:1.93 inches (49 mm)

Drivetrain:Shaft-driven 4WD

Transmission:Single speed

Differential Type:Sealed, hardened steel bevel, limited slip

Gear Pitch:1.0 metric pitch

Servo(s):2085 digital high-torque waterproof

Radio System:TQi™ 2.4 GHz 2-channel transmitter with TSM® receiver

Motor Specs

Motor Name:Velineon™ 1200XL

Motor Type:1275 kV sensorless brushless

Motor Weight:23.44 ounces (665 g)

Motor Length:4.32 inches (110 mm)

Motor Diameter:1.88 inches (48 mm)

Motor Shaft Size:5 mm

Motor Connector Type:6.5 mm bullet connectors

ESC Specs

ESC Name:Velineon™ VXL-8s

ESC Type:Brushless

ESC Case Size:2.23 inches (58 mm) / 2.83 inches (72 mm) / 1.81 inches (46 mm)

ESC Weight:7.60 ounces (215.5 g)

Motor Connectors:6.5 mm bullet connectors

Battery Connectors:Traxxas High-Current Connectors

ESC Power Wire:10 gauge Maxx® Cable
